Stainless Steel Belt Conveyor Systems

A Custom System For Your Unique Application

Belt Technologies can offer complete stainless steel belt conveyor systems to meet most automation needs. The conveyor system is manufactured as a stand-alone unit that is easily integrated into your machine design. The unit is tested for proper pulley alignment, belt tracking and belt tension before shipping, allowing the design engineer a complete conveyor package to insert into their designs. Framing can be extruded aluminum or welded steel, depending on the application. Motors and controls can be added as well. Other customization options include vacuum or timing.

Easily Customize PureSteel^® Conveyor Systems

• Conveyor Belt Length (max): 90’
• Conveyor Belt Width (min): Up to 36” (914.0 mm)
• Belt Type: Solid or perforated stainless or carbon Steel
• Coatings and Surface Treatments: Choose from custom coatings to provide additional properties like improved heat resistance, a nonstick surface and additional wear resistance.
• Rail Type: Fixed, adjustable or combination
• Stand Types: Pedestal, H-style, fixed adjustable, horizontal, incline with floor attachments or casters
• Motor Mount: Above, below or beside conveyor frame
• Speed: Variable
• Electrical Options: 115/230 VAC or 90 VDC – Single or 3-Phase
• Tracking: Optional AutoTrack system continually monitors belt location near idler pulley for precise side-to-side belt positioning
• Timed Drives: Timed (synchronous) belt and pulley features available. Belt positioning of 0.001″ is achievable in a mechanically timed conveyor system.

*Some minor assembly may be required. Consult your Belt Technologies sales engineer for details.

Belt Technologies will work with you to engineer an application-specific design that is easy to install and maintain. Contact us about your PureSteel^® conveyor system project today.
